# Gillespie.jl

## Statement of need

This is an implementation of Gillespie's direct method as well as uniformization/Jensen's method for performing stochastic simulations, which are widely used in many fields, including systems biology and epidemiology. It borrows the basic interface (although none of the code) from the R library `GillespieSSA`

by Mario Pineda-Krch, although `Gillespie.jl`

only implements exact methods at present, whereas `GillespieSSA`

also includes tau-leaping, *etc.*. It is intended to offer performance on par with hand-coded C code; please file an issue if you find an example that is significantly slower (2 to 5 times) than C.

## Installation

The stable release of `Gillespie.jl`

can be installed from the Julia REPL using the following command.

```
using Pkg
Pkg.add("Gillespie")
```

The development version from this repository can be installed as follows.

`Pkg.add("https://github.com/sdwfrost/Gillespie.jl")`

## Example usage

An example of a susceptible-infected-recovered (SIR) epidemiological model is as follows.

```
using Gillespie
using Gadfly
using Random
function F(x,parms)
(S,I,R) = x
(beta,gamma) = parms
infection = beta*S*I
recovery = gamma*I
[infection,recovery]
end
x0 = [999,1,0]
nu = [[-1 1 0];[0 -1 1]]
parms = [0.1/1000.0,0.01]
tf = 250.0
Random.seed!(1234)
result = ssa(x0,F,nu,parms,tf)
data = ssa_data(result)
plot_theme = Theme(
panel_fill=colorant"white",
default_color=colorant"black"
)
p=plot(data,
layer(x=:time,y=:x1,Geom.step,Theme(default_color=colorant"red")),
layer(x=:time,y=:x2,Geom.step,Theme(default_color=colorant"orange")),
layer(x=:time,y=:x3,Geom.step,Theme(default_color=colorant"blue")),
Guide.xlabel("Time"),
Guide.ylabel("Number"),
Guide.title("SSA simulation"),
Guide.manual_color_key("Subpopulation",["S","I","R"],["red","orange","blue"]),
plot_theme
)
```

Julia versions of the examples used in `GillespieSSA`

are given in the examples directory.

## Jensen's method or uniformization

The development version of `Gillespie.jl`

includes code to simulate via uniformization (a.k.a. Jensen's method); the API is the same as for the SSA, with the addition of **max_rate**, the maximum rate (`Float64`

). Optionally, another argument, **thin** (`Bool`

), can be set to `false`

to return all the jumps (including the fictitious ones), and saves a bit of time by pre-allocating the time vector. This code is under development at present, and may change. Time-varying rates can be accommodated by passing a rate function with three arguments, `F(x,parms,t)`

, where `x`

is the discrete state, `parms`

are the parameters, and `t`

is the simulation time.

## The true jump method

The development version of `Gillespie.jl`

also includes code to simulate assuming time-varying rates via the true jump method; the API is the same as for the SSA, with the exception that the rate function must have three arguments, as described above.

## Benchmarks

The speed of an SIR model in `Gillespie.jl`

was compared to:

- A version using the R package
`GillespieSSA`

- Handcoded versions of the SIR model in Julia, R, and Rcpp
- DifferentialEquations.jl's jump interface.

1000 simulations were performed, and the time per simulation computed (lower is better). Benchmarks were run on a Mac Pro (Late 2013), with 3 Ghz 8-core Intel Xeon E3, 64GB 1866 Mhz RAM, running OSX v 10.11.3 (El Capitan), using Julia v0.4.5 and R v.3.3. Jupyter notebooks for Julia and R with the code and benchmarks are available as gists. A plain Julia file is also provided in the benchmarks subdirectory for ease of benchmarking locally.

Implementation | Time per simulation (ms) |
---|---|

R (GillespieSSA) | 463 |

R (handcoded) | 785 |

Rcpp (handcoded) | 1.40 |

Julia (Gillespie.jl) | 1.69 |

Julia (Gillespie.jl, Static) | 0.89 |

Julia (DifferentialEquations.jl) | 1.14 |

Julia (DifferentialEquations.jl, Static) | 0.72 |

Julia (handcoded) | 0.49 |

(smaller is better)

Julia performance for `Gillespie.jl`

is much better than `GillespieSSA`

, and close to a handcoded version in Julia (which is itself comparable to Rcpp); as compiler performance improves, the gap in performance should narrow.

## Future work

`Gillespie.jl`

is under development, and pull requests are welcome. Future enhancements include:

- Constrained simulations (where events are forced to occur at specific times)
- Discrete time simulation

## Citation

If you use `Gillespie.jl`

in a publication, please cite the following.

- Frost, Simon D.W. (2016) Gillespie.jl: Stochastic Simulation Algorithm in Julia.
*Journal of Open Source Software*1(3) doi:0.21105/joss.00042

A Bibtex entry can be found here.
